MicroFlex AC Servo Driver

MicroFlex AC Servo Driver

ABB servo driver, combined with our motion control products and servo and linear motor, can be applied to a variety of applications. These applications include laser cutting and water jet cutting, dispensing, labeling, packaging and positioning cutting, etc. Our simple software tool fully reflects our emphasis on product usability. It simplifies the process of driver debugging and motion control programming, and makes the engineering design of advanced applications simpler.
We can also provide a complete set of intelligent driving system, with advanced control technology, industry-leading performance and simple debugging and many other advantages. A variety of Fieldbus connection options and control interfaces, a wide range of feedback types, more torque and more functions are integrated into a smaller package, so you can make a more compact, more functional device.

Details|

Size|

Recommend|

Case

MicroFlex is a multi-functional brushless servo driver which can drive linear motor torque motor servo motor or third-party motor. MicroFlex debugging is simple as long as the parameters of the motor are input and the software is operated step by step according to the guide steps of the debugging software it is simple and convenient to use.
技术参数
控制器类型MicroFlex
驱动电流(Arms)1,3,6,9(可选)
供电电压单相110VAC-230VAC
编码器反馈数字霍尔EncoderSSI Resolver(可选)
编码器输出1路,差分增量ABZ
工作模式位置控制,速度控制,电流控制
控制接口形式脉冲指令,±10V速度和力矩控制
通讯方式RS232或RS485
数字I/O1input+1output+1使能输入
模拟量输入1路12位±10V分辨率输入
驱动器尺寸180 mm x 80 mm x 157 mm
驱动器重量约 1.55Kg

型号简介
驱动器型号电流及通讯反馈
FMH2A01TR-EN23W持续1 Arms RS232RS485(可选)Encoder/SSI,Resolver(可选)
FMH2A03TR-EN23W持续3 Arms RS232RS485(可选)Encoder/SSI,Resolver(可选)
FMH2A06TR-EN23W持续6 Arms RS232RS485(可选)Encoder/SSI,Resolver(可选)
FMH2A09TR-EN23W持续9 Arms RS232RS485(可选)Encoder/SSI,Resolver(可选)
