| Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
| Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
| VLR-0033-0099-00A | 33 | 8 | 15.2 | 24.3 | 5.62 | 5.87 | 5.87 | 4.33 | 1.42 |
| Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
| N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
| 2.82 | 0.33 | 15.5 | 4.3 | 150 | 9.9 | 0.5 | 23.5 | 137.3 | 160.8 |
