| Performance | Peak Torque | Continuous Torque | With Heat Sink Continuous Torque | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance | |
| Units | N.m | N.m | N.m | V | A | N/A | V/R/s | Ω | mH | |
| VRS0706-014-00A | 7.1 | 2.1 | 2.6 | 52.4 | 6.9 | 1.03 | 1.03 | 7.6 | 7.5 | |
| Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Side clearance of coil | Coil Moment of Inertia | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
| N/vW | ms | ℃/W | ℃/W | ℃ | mm | mm | g-CM² | g | g | g |
| 0.37 | 1 | 3.8 | 2.6 | 150 | 14 | 0.5 | 11520 | 220 | 1170 | 1390 |
