| Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
| Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
| VLR-0001-0010-00A | 0.73 | 0.42 | 0.73 | 4.8 | 1.21 | 0.603 | 0.603 | 4 | 0.03 |
| Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
| N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
| 0.3 | 0.008 | 62.7 | 14.4 | 150 | 1 | 0.5 | 2.7 | 6.9 | 9.6 |
