Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
VLR-0022-0448-00A | 22 | 11.4 | 17.5 | 14.3 | 5.5 | 4 | 4 | 2.6 | 0.64 |
Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
2.48 | 0.25 | 5.9 | 2.5 | 150 | 44.8 | 0.4 | 52 | 789 | 841 |
