Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant常数 | Resistance | Inductance |
Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
VLR-0032-0050-00A | 32 | 8.9 | 15 | 29.3 | 4.5 | 7.1 | 7.1 | 6.5 | 3.3 |
Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
2.78 | 0.51 | 12.2 | 4.3 | 150 | 5 | 0.5 | 51 | 254 | 305 |
