Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
VLR-0044-0059-00A | 44 | 17.7 | 41.3 | 14.3 | 5.5 | 8 | 8 | 2.6 | 0.95 |
Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
4.96 | 0.37 | 9.8 | 1.8 | 150 | 5.9 | 0.5 | 43 | 173 | 216 |
