| Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
| Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
| VLR-0087-0563-00A | 87 | 17.5 | 18.2 | 63.4 | 10.7 | 8.1 | 8.1 | 5.9 | 4.2 |
| Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
| N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
| 3.33 | 0.71 | 4.5 | 4.2 | 150 | 56.3 | 0.5 | 170 | 2580 | 2750 |
