Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant常数 | Resistance | Inductance |
Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
VLR-0105-0164-00A | 105 | 35.4 | 57.1 | 20.1 | 9.1 | 11.5 | 11.5 | 2.2 | 2.15 |
Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
75 | 0.98 | 6 | 2.3 | 150 | 16.4 | 0.5 | 150 | 582 | 732 |
