Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
VLR-0249-0498-00A | 294 | 56.8 | 59.9 | 114 | 12 | 24.5 | 24.5 | 9.5 | 20 |
Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
7.95 | 2.1 | 2.45 | 2.2 | 150 | 49.8 | 0.4 | 700 | 5140 | 5840 |
