Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
VLR-0436-0250-00A | 436 | 167 | 214 | 31.6 | 11.7 | 37.2 | 37.2 | 2.7 | 4.8 |
Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
22.6 | 1.78 | 2.3 | 1.4 | 150 | 25 | 0.5 | 740 | 2320 | 3060 |
