Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
Units | N | N | N | V | A | N/A | V/M/S | Ω | mH |
VLR-1351-0310-00A | 1351 | 377 | 472 | 73.5 | 19.9 | 68 | 68 | 3.7 | 5.8 |
Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Coil Side Clearance | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
35.3 | 1.6 | 1.1 | 0.7 | 150 | 31 | 0.5 | 1050 | 7773 | 8823 |
