Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
Units | N | N | N | V | A | N/A | V/m/s | Ω | mH |
VLS0013-0343-00A | 13 | 8 | 12.5 | 12.6 | 2.2 | 5.8 | 5.8 | 5.6 | 1.6 |
Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Magnetic Steel Weight | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
2.45 | 0.29 | 11.7 | 4.8 | 150 | 34.3 | 0.5 | 40 | 440 | 480 |
