Home >> Products >> Voice Coil Motor >> VLS Series Motor
Details|
Size|
Recommend|
Case
| Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
| Units | N | N | N | V | A | N/A | V/m/s | Ω | mH |
| VLS0065-1000-00A | 65 | 22.4 | 29.2 | 28.7 | 6.7 | 9.7 | 9.7 | 4.28 | 3.45 |
| Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Magnetic Steel Weight | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
| N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
| 4.69 | 0.81 | 5.5 | 3.23 | 150 | 100 | 0.5 | 135 | 3720 | 3855 |
