Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance | Inductance |
Units | N | N | N | V | A | N/A | V/m/s | Ω | mH |
VLS0750-1000-00A | 681 | 137.6 | 152.1 | 122.6 | 22.7 | 30 | 30 | 5.4 | 21 |
Motor Constant | electrical time constant | Thermal Resistance | With Heat SinkThermal Resistance | Max Winding Temp | Stroke | Magnetic Steel Weight | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
N/√W | ms | ℃/W | ℃/W | ℃ | mm | mm | g | g | g |
12.9 | 3.89 | 1.1 | 0.9 | 150 | 100 | 1.2 | 1900 | 10600 | 12500 |
