Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance |
Units | N | N | N | V | A | N/A | V/M/S | Ω |
VCA0006-0080-00A | 6.2 | 2.6 | 4.57 | 15.7 | 1.74 | 3.57 | 3.57 | 9.05 |
Inductance | Motor Constant | electrical time constant | Max Winding Temp | Stroke | Magnetic Steel Weight | Coil Weight | Magnetic Steel Weight | MotorTotal Weight |
mH | N/Vw | ms | ℃ | mm | g | g | g | g |
0.9 | 1.19 | 0.099 | 150 | 8 | 0.5 | 13 | 46 | 218 |
