| Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Inductance |
| Units | N | N | V | A | N/A | V/m/s | Ω | ℃ |
| VCA0033-0150-00A | 25 | 14 | 30 | 3 | 8.3 | 8.3 | 9.1 | 6.3 |
| Motor Constant | electrical time constant | Max Winding Temp | Stroke | Magnetic Steel Weight | Coil Weight | Magnetic Steel Weight | MotorTotal Weight | |
| Units | N/Vw | ms | ℃ | mm | mm | mm | g | g |
| VCA0033-0150-00A | 2.7 | 0.3 | 120 | 10 | 0.4 | 60.2 | 570 | 2000 |
