| Performance | Peak Force | Continuous Force | With Heat SinkContinuous Force | Maximum Voltage | Maximum Current | Force Constant | Bank EMF Constant | Resistance |
| Units | N | N | N | V | A | N/A | V/m/S | Ω |
| VCA0087-0563-00A | 87 | 17.5 | 18.2 | 63.4 | 10.7 | 8.1 | 8.1 | 5.9 |
| Inductance | Motor Constant | electrical time constant | Max Winding Temp | Stroke | Magnetic Steel Weight | Coil Weight | Magnetic Steel Weight | Maximum load |
| mH | N/√W | ms | ℃ | mm | mm | g | g | g |
| 4.2 | 3.33 | 0.71 | 150 | 56.3 | 0.5 | 170 | 2580 | 2000 |
